Z446-K Refrigerated Benchtop Universal Centrifuge
- HIGH CAPACITY 4 x 750 mL swing out rotor, 68 x 15 mL or 28 x 50 mL
- Ideal for Tissue Culture applications
- Advanced programming with automatic rotor recognition
- Available with refrigeration
The Z446 universal centrifuge series offers the highest capacity of any benchtop Hermle-Benchmark model. With air-craft grade, premium alloy construction, the 4 x 750 mL swing out rotor can withstand centrifugal forces upwards of 4,500 xg with full loads of up to 28 x 50 mL or 68 x 15 mL tubes.
Advanced microprocessor controls allow for instant rotor identification,which automatically converts the rotational speed to the relevant g-force (rcf), preventing the user from setting a speed above the capabilities of the installed rotor. In addition to retrieving saved programs, the easy to use front panel can adjust accel/decel rates, and change the end of run alarm tone. Rotor exchange is simple and requires less than one minute. An included rotor wrench can be used to loosen and install all rotors. As soon as the rotor is placed on the motor shaft, the identification process activates and the installed rotor code is displayed on the backlit LCD display.
Specifications
| Speed Range | 200 to 16,000 rpm |
| Max. RCF | 24,325 xg |
| Max. Capacity | 4 x 750 mL |
| Temp. Range | -20°C to 40°C (Z446-K only) |
| Dimensions | 21.3 x 26.4 x 15.4 in. (54.1 x 67 x 39.1 cm.) 28.7 x 26.4 x 15.4 in. (-K) (72.9 x 67 x 39.1 cm.) |
| Timer | up to 99 hr, 59min and continuous |
| Weight | 174 lbs / 244 lbs (-K) |
| Electrical | 115 V, 60 Hz |
| Power (Watts) | 600 W / 1630 W (-K) |
| Z446-K | Z446-K Refrigerated Centrifuge, 115 V |
| Z446-750-AC | 4 x 750 swing out rotor |
| Z446-750 | 4 x 750 swing out rotor with buckets |
| Z446-750-BUK | Round buckets for Z446-750-AC 2/pk |
| Z446-750-MP | microplate carriers, 2/pk. |
| Z446-MP-STK | PCR stacking adapter for Z446-750-MP, 2/pk |
| Z326-MPCA | 3 x chamber slide and 35/60mm dish carrier 2/pk |
| Z446-750-A500 | 500 mL conical (Corning) insert, 2/pk. |
| Z446-750-A250 | 250 mL flat bottle insert, 2/pk |
| Z446-750-A225 | 225 mL conical insert, 2/pk |
| Z446-750-A50 | 7 x 50 insert, 2/pk |
| Z446-750-A30 | 8 x 30 mL insert, 2/pk |
| Z446-750-A15 | 17 x 15 mL insert, 2/pk |
| Z446-750-A10 | 21 x 10 mL insert, 2/pk |
| Z446-750-A57 | 32 x 5/7ml insert, 2/pk |
| Z446-750-LID | Lid for Z446-750 2/pk |
| Z446-MP-BUK | Rectangular buckets for Z446-750-AC 2/pk |
| Z326-MPCA | 3 x chamber slide and 35/60 mm dish carrier 2/pk |
| Z446-MP-LID | Lid for Z446-MP-BUK 2/pk |
| Z446-MP-RA | Removing Aid for Z446-MP-BUK 2/pk |
| Z446-04500 | 4 x 500 mL angle rotor |
| Z446-500-A250 | 250 mL conical insert for 500 mL rotor, 2/pk |
| Z446-500-A250F | 250 mL bottle insert for 500 mL rotor, 2/pk |
| Z446-500-A50 | 50 mL conical insert for 500 mL rotor, 2/pk |
| Z446-500-A50R | 3 x 50 mL round insert for 500 mL rotor, 2/pk |
| Z446-500-A15 | 6 x 15 mL conical insert for 500 mL rotor, 2/pk |
| Z366-06250 | 6 x 250 angle rotor |
| Z366-06250-A15 | Adapter 4 x 15 mL conical |
| Z366-06250-A50R | Adapter 50 mL round |
| Z366-06250-A50 | Adapter 50 mL conical |
| Z326-0685 | 6 x 85 mL High Speed rotor (38°) |
| Z326-85-A50 | 50 mL insert, 2/pk |
| Z326-85-A50R | 50 mL round insert, 2/pk |
| Z326-85-A15 | 15 mL conical insert, 2/pk |
| Z326-85-A15R | 10 - 15 mL round insert, 2/pk |
| Z326-0485 | 4 x 85 mL rotor |
| Z326-85-A50 | 50 mL insert, 2/pk |
| Z326-85-A50R | 50 mL round insert, 2/pk |
| Z326-85-A15 | 15 mL conical insert, 2/pk |
| Z326-85-A15R | 10 - 15 mL round insert, 2/pk |
| Z326-1050 | 10 x 50 mL Conical Rotor |
| Z326-50-A15 | 15 mL Adapter for conical 50 mL rotors 2/pk |
| Z206-50-A57 | 5-7 mL round adapter for 50 mL rotors, 6/pk |
| Z206-50-A57C | Cushion for 5 mL tube in Z0232-9B adapter, 6/pk |
| Z326-0650-HS | 6 x 50 mL Round rotor (12,000 rpm) |
| Z326-50-A15R | Adapter for 10-16 mL (16 mm) round for 50 mL rotors |
| Z326-50-A30 | Adapter for 30 mL round for 50 mL rotors |
| Z326-2010 | 20 x 10 mL High Speed Rotor |
| Z326-02MP | 2 x microplate rotor |
| BT1500-A1520 | 20 x 1.5 mL for microplate rotor |
| BT1500-A05 | 20 x 0.5 mL for microplate rotors |
| Z326-MPCA | 3 x chamber slide and 35/60 mm dish carrier 2/pk |
| Z326-2420 | 24 x 1.5/2.0 mL rotor |
| Z326-2420H | 24 x 1.5/2.0 mL Hermetically sealed rotor |
| Z326-3202 | 4 x pcr rotor |
| Z326-4420 | 44 x 1.5/2.0 mL rotor |
