Home  >  Cold Storage  >  Refrigerators  >  Chromotography Refrigerators  > Chromatography Refrigerator

Chromatography Refrigerator

Item #: ASCGROMREF

3 Years Parts and Labor, 7 Years on the Compressor.

Glass Door Chromatography Refrigerators

Swing Doors
Sliding Doors

AT-23C
AT-49C
AT-72C
AT-33C
AT-47C
AT-69C
Capacity (cu.ft.)
23
49
72
33
47
69
Temperature Range
0.5°C to 3.3°C / 33°F to 38°F
No. of Doors
1
2
3
2
2
3
No. of Shelves
4
8
12
8
8
12
Adjustable Shelves
Yes
Shelf Type
Heavy Duty PVC Coated Wire Shelves
Interior Dimensions (WxDxH) (in)
23.5 x 25.25 x 57
50.5 x 25.25 x 56
74.75 x 25.25 x 57
36 x 24.75 x 57
50.63 x 24.75 x 56
74.63 x 24.75 x 61.25
Exterior Dimensions (WXDXH) (in)
27 x 29.5 x 78.25
54 x 29.88 x 78.63
78.13 x 29.88 x 79.63
39.5 x 29.63 x 78.63
54.13 x 29.63 x 78.63
78.13 x 29.56 x 79.38
Refrigeration System
CFC-Free
Glass Doors
"Low-E", Double Pane Thermal Insulated
Maximum Clearance (in)
24.94
24.94
23.81
Left Door: 15.00 / Right Door: 14.75
Left & Right Doors: 22.13
Left Door: 22.25 / Right Door: 21.1
Cord Length
9 ft
NEMA Configuration
5-15P
Compressor Horsepower (HP)
0.333
0.5
0.75
0.333
0.5
0.75
Electrical Current (amps)
5.2
7.3
6.5
6.2
8.8
6.5
Voltage
115 V / 60 W
Shipping Weight (lbs)
355
490
670
405
485
675
Warranty
3 Years Parts and Labor, 7 Years on the Compressor

Accessories:

ATC1

Digital Temperature Alarm

AP-01

Access Ports 2.25 in Diameter

C-1

Casters for 1 & 2 door models, (set of 4)

C-2

Casters for 3 door models & AT-61, AT61C (set of 6)

LC-33

Barrel lock (factory installed) for 2 door models with sliding doors

LC-100

Ratchet lock for 2 door models with sliding doors

LC-200

Ratchet lock for 3 door models with sliding doors (2) locks

Tip Top™ Dispenser Caps

  • Convenient and Easy: Just tilt the tube and squeeze Tip Top® slightly to dispense one drop onto a slide.
  • Safe Dispensing: You don't need to open the tube preventing spillage and exposure to infectious agents.
  • Very Low Evaporation: A flexible cap is available to cover the Tip Top® so you can store samples longer.
  • Medical Grade Resins: USP Class medical grade resins and packaging.

Safe Dispensing of Blood Samples
Tip Top® Dispenser Caps A safe and cost-effective way of dispensing samples in your lab. The Tip Top® is a disposable cone shaped cap that fits all standard 13 or 16mm blood collection tubes. A small opening allows you to dispense a sample without removing the Tip Top cap so you can prepare smears on slides or dispense into reagent wells or microcentrifuge tubes safely. Inside the tip of the Tip Top® is an integral porous filter that removes fibrin from the blood sample allowing for a perfect smear.

Tip Top® is a convenient alternative to pipetting from an open blood tube, just tilt the tube and squeeze to dispense one drop. And Tip Top® is safe you don't need to open the tube and pipet out of the tube so spillage is reduced along with potential exposure to infectious disease. Just carefully remove the stopper and replace with Tip Top®.

The Tip Top® dispenser cap can be used with almost any liquid. Made from chemically resistant polyethylene they can dispense serum, reagents, plasma, whole blood and CSF. The integral porous polyethylene filter efficiently separates serum and can also be used a a reagent blender.

Fits standard 13 x 100 and 16 x 100 collection tubes.


MIDSCI # VWR #
5511-800-000-9 30128-604
5512-800-000-9 N/A

PNBLOOD

Qty
5 bags of 1000 caps
SKU Number Refrigerator Type Cu. Ft Price Quantity Add to Cart
AT-23C Chrom Frig 23
7528.00
Each
AT-33C Chrom Frig 33
10073.00
Each
AT-47C Chrom Frig 47
11940.00
Each
AT-49C Chrom Frig 49
12026.00
Each
AT-69C Chrom Frig 69
15562.69
Each
Chromatography Family
Chromatography Refrigerator
Special Order
Quantity:
