SmartDoc™ Imaging System

Item #: ASGELDOC1

2 year warranty

Technical Data:

Specifications GCM-24 GCM-R-24
Maximum Speed 15,000 rpm (200-15,000 rpm),
10 rpm increment
15,000 rpm (200-15,000rpm),
10 rpm increments
Maximum RCF 21,380 x G, (10 x G Increment) 21,380 x G, (10 x G increments)
Speed Accuracy +/- 20 rpm +/- 20 rpm
Temperature N/A -20°C to 40°C
Rotor Capacity Twenty-Four (24) 1.5 / 2.0 mL tubes Twenty-four (24) 1.5 / 2.0 mL tubes
Run Time 30 sec - 99 min or continuous 30 sec - 99 min or continuous
Power 5A, 500W 10A, 400W
Acceleration Time 25 Seconds 25 Seconds
Braking Time 25 Seconds 25 Seconds
Dimension (W x D x H) 280 x 364 x 266 mm
(11.0 x 14.3 x 10.5")
338 x 580 x 324 mm
(13.3 x 22.8 x 12.8")
Weight 12 Kg (26.5 lbs) 30 Kg (66.1 lbs)
Certifications CE, cTÜVus, FCC, MCA CE, cTÜVus, FCC, MCA
Warranty 2 Years 2 Years

Microcentrifuge Accessories:

GCM-24-AD2:  Rotor Adapters for GCM-12, GCM-24, GCH-24 for 0.2mL Tubes, 24/bag

GCM-24-AD5:  Rotor Adapters for GCM-12, GCM-24, GCH-24 for 0.5mL Tubes, 24/bag

GCM-24-5MLR:  Rotor for use with GCM-24 Series, 15000rpm max, 18-Place for 5mL Tubes

GCM-24-5ML:  Rotor for use with GCM-24 Series, 15000rpm max, 12-Place for 5mL Epp*

GCM-24-05ML:  Rotor for use with GCM-24 Series, 15000rpm max, 36-Place, for 0.5mL MCTs

GCM-24-PCR:  Rotor for use with GCM-24 Series, 15000rpm max, 4 x 8 positions for 0.2mL PCR Tubes

GCM-24-AD52:  Rotor Adapters for GCM-24-05ML Rotor for 0.2mL Tubes, 36/bag

GCM-AD2:  Rotor Adapter for use with GCM Series for 0.2mL MCT Tubes, 8/bag

GCM-AD5:  Rotor Adapter for use with GCM Series for 0.5mL MCT Tubes, 8/bag



Homogenizer

The PRO200 homogenizer is ideal for microprocessing in 0.5 ml, 1.5 ml or 2.2 ml microtubes. With PRO's standard Micro-Homogenizing Package, which includes the PRO200 homogenizer and the industry's smallest generator, the 5 x 75 mm generator, volumes as small as 0.03 ml can be easily processed in a matter of seconds. Whether gently mixing, extracting RNA/DNA or destroying the cell wall, the PRO Micro-Homogenizing Package can effectively and efficiently process your sample.

The PRO Micro-Homogenizing Package is available in three styles, the Standard version, Deluxe version or Premium version. The Deluxe Micro-Homogenizing Package features two generators,the 5 x 75 mm generator as well as the 7 x 95 mm generator. The 7 x 95 mm generator features a saw tooth design, which makes it ideal for processing tougher samples. The Premium Micro-Homogenizing Package is the ultimate setup for microprocessing. This package includes the PRO200 homogenizer , both the 5 x 75 mm and 7 x 95 mm generators as well as the PRO200 stand assembly for hands free homogenizing.


Standard Micro-Homogenizing Package: Includes PRO200 homogenizer and 5 X 75mm flat bottom generator. p/n PK-01200S (115V), PK-02200D (220V)


Deluxe Micro-Homogenizing Package: Includes PRO200 homogenizer, toolkit,5 x 75 mm flat bottom generator and 7 x 95 mm saw tooth bottom generator. p/n PK-01200D (115V) PK-02200D (220V)

Premium Micro-Homogenizing Package
: Includes PRO200 homogenizer, toolkit,5 x 75 mm flat bottom generator and 7 x 95 mm saw tooth bottom generator and PRO200 stand assembly. p/n PK-01200P (115V) PK-01200P (220V)

SKU Number Type Wavelength MP of Camera Grayscale Trans Size Price Quantity Add to Cart
E5001-SD Imaging Enclosure N/A N/A N/A N/A
435.75
Each
E5001-SDB System with Blue Light N/A N/A N/A 16 x 16 cm
750.75
Each
E5000-535 Narrow Band Pass Filter 535nm for Green stains N/A N/A N/A
127.05
Each
E5000-590 Narrow Band Pass Filter 590nm for EtBr N/A N/A N/A
127.05
Each
E5000-MAT UV Blocking Mat N/A N/A N/A N/A
40.00
Each
E4000-VG1 SmartBlue Plus Viewing Glasses Blocks Blue Light & UV N/A N/A N/A
48.00
Each
SmartDoc 2.0
SmartDoc™ Imaging System
Special Order
Quantity:
