Tecan Style Robotic Pipette Tips

The Tecan Robotic Tips fit the Tecan MCA®, Genesis Freedom®, Freedom Evo®, and Miniprep with Liha®). This is designated in the above ordering chart. These tips provide reservoirs for High Throughput Screening (HTS) samples and reagent storage. Used in proteomics, drug development and genomics.

• Case dimensions are
• 20 uL (Genesis Freedom®, Freedom Evo®, and Miniprep with Liha®): 465(L) x 295(W) x 345(H)
• 50 uL & 200 uL (MCA): 480(L) x 345(W) x 280(H) mm
• 50 uL & 200 uL (Genesis Freedom®, Freedom Evo®, and Miniprep with Liha®): 465(L) x 295(W) x 455(H)
• 500 uL (MCA): 500(L) x 285(W) x 405(H) mm
• 1000 uL (Genesis Freedom®, Freedom Evo®, and Miniprep with Liha®): 685(L) x 295(W) x 465(H)
• Gross weight is
• 20 uL & 50 uL (Genesis Freedom®, Freedom Evo®, and Miniprep with Liha®): 10.6 kg
• 50 uL, 200 uL, & 500 uL (MCA): 10.5 kg
• 200 uL (Genesis Freedom®, Freedom Evo®, and Miniprep with Liha®): 11.6 kg
• 1000 uL (Genesis Freedom®, Freedom Evo®, and Miniprep with Liha®): 17.4 kg
• 96 tips/hanging tip rack format (MCA)
• 96 tips/hanging tip rack format stack. Double stack box packaging (Genesis Freedom®, Freedom Evo®, and Miniprep with Liha®)
• Polypropylene
• Available filtered and non-filtered
• Available presterilized and nonsterile
• Certified RNase and DNase Free
• Nonpyrogenic
• Endotoxin-Safe meets USP/FDA Standards
• Comply with USP 3127 (Heavy Metal Contamination) standard

Tips for the Genesis Freedom®, Freedom Evo®, and Miniprep with Liha® are liquid level sensing tips
