TPP Bioreactors

Item #: ASTPTBSPINS

Order # Description Working Vol (mL) Dimensions (mm) Material Max g Force Packaging Quantity
TP87017-200 15 mL Tubespin Bioreactors, Round 1-10 mL 17.1 x 120 PP 15500 40/pk, 5 pks/cs 200/cs
TP87017-400 15 mL Tubespin Bioreactors, Round 1-10 mL 17.1 x 120 PP 15500 40/pk, 10 pks,cs 400/cs
TP87017 15 mL Tubespin Bioreactors, Round 1-10 mL 17.1 x 120  PP 15500 40/pk, 20 pks/cs 800/cs
TP87015 15 mL Tubespin Bioreactors, Conical 1-10 mL 17.1 x 120 PP 15500 40/pk, 20 pks/cs 800/cs
TP87050-60 50 mL Tubespin Bioreactors, Conical 1-35 mL 30 x 115 PP 15500 20/pk, 3 pks/cs 60/cs
TP87050 50 mL Tubespin Bioreactors, Conical 1-35 mL 30 x 115 PP 15500 20/pk, 9 pks,cs 180/cs
TP87056 50 mL Tubespin Bioreactors, Round 1-35 mL 30 x 115 PP 15500 20/pk, 9 pks,cs 180/cs
TP86050 50 mL Tubespin Bioreactors, Conical with Septum 1-35 mL 30 x 115 PP/PE 15500 20/pk, 9 pks/cs 180/cs
TP87450 450 mL Tubespin Bioreactors, Conical 300 mL 96 x 145 PP 3500 32/pk 32/cs
TP87600-3 600 mL Tubespin Bioreactors, Conical 400 mL 100 x 183 PP 3500 3/pk 3/cs
TP87600-13 600 mL Tubespin Bioreactors, Conical 400 mL 100 x 183 PP 3500 13/pk 13/cs
TP87600 600 mL Tubespin Bioreactors, Conical 400 mL 100 x 183 PP 3500 26/pk 26/cs
TP99013 Rack for Three 600 mL Bottles 3 x TP87600 366 x 146 x 70 PP N/A 1/pk, 6 pks/cs 6/cs
TP80617 Rack for 15 / 50 mL Tubes 18 x 15 mL / 10 x 50 mL 209 x 98 x 62 PP N/A 1/ea 1/ea
TP87411 Adapter Plate 32 x 450 mL for Kuhner Shaker 32 x 450 mL 800 x 420 Alu N/A 1/ea 1/cs
TP87431 Adapter Plate 32 x 450 mL for Infors Multitron Shaker 32 x 450 mL 850 x 470 Alu N/A 1/ea 1/cs
TP87611 Adapter Plate 32 x 600 mL for Kuhner Shaker 32 x 600 mL 800 x 420 Alu N/A 1/ea 1/cs
TP87612 Adapter Plate 20 x 600 mL for Kuhner Shaker 20 x 600 mL 500 x 420 Alu N/A 1/ea 1/cs
TP87613 Adapter Plate 16 x 600 mL for Kuhner Shaker 16 x 600 mL 420 x 420 Alu N/A 1/ea 1/cs
TP87631 Adapter Plate 32 x 600 mL for Infors Multitron Shaker 32 x 600 mL 850 x 470 Alu N/A 1/ea 1/cs
TP87633 Adapter Plate 16 x 600 mL for Infors Multitron Shaker 16 x 600 mL 480 x 420 Alu N/A 1/ea 1/cs
Microplate Absorbance Rea

SmartReader™ 96 Microplate Absorbance Reader

  • Intuitive, 7-inch color touch screen control panel
  • Filter based system with wavelength range from 340 to 750 nm
  • Operates as a stand-alone system, with USB flash drive for data transfer
  • Absorbance range: 0.0 to 4.0000 Abs
  • 8 channel vertical optical path, with zero dispersion
  • Integrated, multi-speed plate shaker
  • MR9600-T features temperature-controlled plate incubation


The Accuris™ SmartReader™ 96 MR9600 and MR9600-T are welcome additions to any lab that is routinely measuring concentration or absorbance in 96 well plates. The 7-inch touchscreen, intuitive software and graphical interface make these instruments easy to use as a standalone reader (a separate computer and additional software is not required).

The SmartReader™ 96 comes complete with 4 popular filters: 405, 450, 492, 630 nm and twenty six additional filters are available separately to cover a full range from 340 to 750 nm. The integrated filter wheel allows up to 8 filters to be loaded at once, and filters can be selected during programming

Use the touchscreen or connect a mouse for programming and operation. The menu interface allows the user to choose the wavelength filter, set shaking parameters, enter details of the plate layout, and choose the details for the reading protocol and data calculations.

Model MR9600-T offers precise temperature control for incubation of plates during processing. Temperature can be maintained at 5°C above ambient to 50°C.

Up to two filters can be used for 2 measurements of the sample plate, for calculated comparisons. Kinetic calculations can be performed by setting multiple readings.

The SmartReader™ 96 is a convenient stand-alone reader, all software and the programing system is incorporated into the electronics. However, a convenient USB port on the side allows quick and easy saving of data files to a USB drive, and the universal .csv files can then be shared or transferred to a computer for storage or further processing. A data port can be used for connecting a computer or basic printer.

The plate layout interface allows for quick and intuitive set up of a plate's well contents.  The display shows a graphical representation of the 96 well plate, and the user can label each well as required for: "known standard", "unknown sample", "blank well", "QC control well", "negative control", "positive control", or "empty".  The interface allows highlighting and labeling multiple wells to save time.

Measurement data is available immediately on the screen after a reading, as well as interpretations, calculated analysis, and curve fittings.


Click here to Watch Specs Video!



Specifications


ModelAccuris™ SmartReader™ 96
Control and Display7 inch touch screen
(800 x 480 pixels)
Light SourceQuartz-halogen lamp 6V/10W
Wavelength range340-750 nm
(405, 450, 492 and 630 nm filters included)
Half-Bandwidth of filter3~9 nm
Readout Range0~4.000 Abs
Linearity (405 nm)0~2.000 Abs <+1%
0~4.000 Abs <+2%
SKU Number Size Bottom Qty Price Quantity Add to Cart
TP86050 50 mL with septum Conical 180
2380.95
Each
TP87015 15 mL Conical 800
949.98
Each
TP87017 15mL Round 800
1423.50
Each
TP87017-200 15mL Round 200
354.62
Each
TP87017-400 15mL Round 400
713.01
Each
TP87050 50 ml Conical 180
413.90
Each
TP87050-60 50 ml Conical 60
152.06
Each
TP87056 50 mL Round 180
645.66
Each
TP87411 Adapter Plate 450 for Kuhner Shaker 1
4160.68
Each
TP87450 400 mL Conical 32
550.31
Each
TP87600 600ml Conical 26
868.24
Each
TP87600-13 600ml Conical 13
432.59
Each
TP87600-3 600ml Conical 3
100.28
Each
TP87611 Adapter Plate 32 for Kuhner Shaker 1
4926.46
Each
TP87612 Adapter Plate 20 for Kuhner Shaker 1
3889.44
Each
TP87613 Adapter Plate 16 for Kuhner Shaker 1
3373.66
Each
TP87631 Adapter Plate 32 for Infors Shaker 1
4896.25
Each
TP87633 Adapter Plate 16 for Infors Shaker 1
3416.98
Each
TP99013 Rack for three 600 mL Bottles N/A 6 racks
268.71
Each
